Table 4-6 Right door assembly
Ref Description Part number Qty
Right door assembly, duplex model RM1-6007-000CN 1
Right door assembly, simplex model RM1-6138-000CN 1
1 Roller, secondary transfer, T2 (included in the service kit) CC522-67912 1
2 Door, right upper RC2-7091-000CN 1
3 Roller, paper pick-up, Tray 1 (included in the service kit) CC522-67928 1
4 Lifter plate assembly, Tray 1 RM1-6043-000 1
5 Pick roller and separation pad, Tray 1 (included in the service kit) CC522-67928 1
6 Tray 1 (MP tray) assembly RM1-6045-000CN 1
ENWW Right door assembly 551
