HP M750 series

Table 4-7 Internal components (1 of 9)
Ref Description Part number Qty
1 Upper cartridge guide assembly RM1-5990-000CN 1
2 Duct, front RC2-7300-000CN 1
3 Stopper, inner door, 1 RC2-6719-000CN 1
4 Stopper, inner door, 2 RC2-6736-000CN 1
5 Door, inner, service kit includes all labels CC522-67906 1
6 Cover, lower front RC2-6737-000CN 1
11 Spring, grounding RC2-7209-000CN 1
12 Hinge, inner door, left RC2-6716-000CN 1
13 Hinge, inner door, right RC2-6712-000CN 1
14 Rail, cartridge auxiliary RC2-6724-000CN 1
15 Mount, cover arm, front RC2-6735-000CN 1
16 Arm, front cover, 1 RC2-6732-000CN 2
17 Mount, inner door toggle RC2-6717-000CN 1
18 Arm, front cover, 2 RC2-6733-000CN 2
19 Mount, stopper arm RC2-6745-000CN 2
20 Mount, inner door rail RC2-6743-000CN 1
21 Spring, compression RU6-2721-000CN 1
22 Lever, inner door pressure RC2-6744-000CN 1
23 Hinge, front cover, left RC2-6713-000CN 1
24 Hinge, front cover, center RC2-6738-000CN 1
25 Hinge, front cover, right RC2-6715-000CN 1
26 Cover, guide RC2-7204-000CN 1
27 Guide, arm, front RC2-6632-000CN 1
28 Lever, push RC2-7198-000CN 1
29 Lever, lift, 2 RC2-7200-000CN 1
30 Microswitch WC4-5251-000CN 1
ENWW Internal components (1 of 9) 553
