Table 4-9 Internal components (3 of 9)
Ref Description Part number Qty
1 Drive assembly, duplex reverse, duplex model RM1-6005-000CN 1
1 Drive assembly, simplex reverse, simplex model RM1-6120-000CN 1
2 Guide, fuser, front RC2-6546-000CN 1
3 Cover, cable, protective RC2-6832-000CN 1
4 Fuser assembly, 110V (included in service kit) CE707-67912 1
4 Fuser assembly, 220V (included in service kit) CE707-67913 1
5 Guide, fuser, rear RC2-6547-000CN 1
6 Fuser drive assembly CE707-67904 1
7 Fuser motor assembly RM1-6074-000CN 1
8 Gear assembly, fuser RM1-7914-060CN 1
9 Cable, SB joint, low-voltage power supply, duplex model RM1-6867-000CN 1
10 Spring, tension, registration sensor RU6-2710-000CN 2
11 Support, frame, rear RC2-7197-000CN 1
12 Registration sensor assembly RM1-7922-000CN 1
13 Support, frame, front RC2-7196-000CN 1
14 Tray 2 pickup and separation roller assembly (included in service kit) CE710-69007 1
15 Connector, snap tight, black VS1-7207-019CN 1
16 Guide, paper feed RC2-7297-000CN 1
17 Sensor, cassette last paper presence RM1-6164-000CN 1
18 Cover, connector, lower RC2-6642-000CN 1
19 Gear, 18T/29T RU6-0775-000CN 1
20 Label, fuser insert RU6-8042-000CN 1
ENWW Internal components (3 of 9) 557
