Table 4-10 Internal components (4 of 9)
Ref Description Part number Qty
1 Cover, main drive cable, lower RC2-6574-000CN 1
2 Guide, main drive cable RC2-6659-000CN 1
3 Main drive assembly, duplex model CE708-67901 1
3 Main drive assembly, simplex model CE707-67905 1
4 DC motor assembly RM1-6088-000CN 3
5 Motor, stepping, DC, duplex model RK2-3298-000CN 2
5 Motor, stepping, DC, simplex model RK2-3298-000CN 1
6 Cable, feed joint, duplex model RM1-6846-000CN 1
7 Spring, grounding, second-transfer high-voltage PCA RU6-2772-000CN 1
8 Holder, secondary transfer HVT RC2-6681-010CN 1
9 Cap, T2 contact, second-transfer high-voltage PCA RC2-6691-000CN 1
10 Spring, contact, second-transfer high-voltage PCA RU6-2771-000CN 1
11 Holder, secondary transfer, power dispatching RC2-6682-000CN 1
12 Spring, grounding, second-transfer high-voltage PCA RC2-6700-000CN 1
13 Link, ITB coupling release RC2-6823-000CN 1
14 Spring, tension, duplex model RU6-2671-000CN 1
15 Hook, duplexing spring, duplex model RC2-6932-000CN 1
16 Gear, 25T, duplex model RU6-0771-000CN 1
17 Cover, duplexing gear, duplex model RC2-6931-000CN 1
18 Gear, 25T, duplex model RU6-0772-000CN 1
19 Gear, 74T, duplex model RU6-0773-000CN 1
20 Plate, duplexing drive gear RL1-2266-000CN 1
21 Support, developing coupling RC2-6811-000CN 4
22 Cover, gear, simplex model RC3-0688-000CN 1
23 Sensor, right door WG8-5935-000 1
24 Holder, door sensor, right RC2-6645-000CN 1
25 Arm, ITB coupling release RC2-6824-000CN 1
26 Rail, door link, rear lower RC2-6635-000CN 1
27 Spring, tension, rear RU6-2744-000CN 1
28 Plate, right door link, rear RC2-7273-000CN 1
29 Plate, right door link, fixed, rear RL1-2282-000CN 1
30 Shaft, right door link RU5-4979-000CN 2
ENWW Internal components (4 of 9) 559
