Table 4-11 Internal components (5 of 9)
Ref Description Part number Qty
31 Lock, door link, right RC2-7234-000CN 2
32 Link, right door, 2 rear RC2-7236-000CN 1
33 Link, right door, 2 front RC2-7233-000CN 1
34 Duct, joint RC2-8360-000CN 1
35 Plate, right door link, fixed, front RL1-2281-000CN 1
36 Hinge, right door, front RC2-7094-000CN 1
37 Plate, right door link, front RC2-7272-000CN 1
38 Spring, tension, front RU6-2727-000CN 1
39 Rail, door link, front lower RC2-6634-000CN 1
ENWW Internal components (5 of 9) 561
