Table 4-12 Internal components (6 of 9)
Ref Description Part number Qty
1 IT belt guide rail assembly RM1-6018-000CN 1
2 IT belt guide rail R1 assembly RM1-6037-000CN 1
3 Toner collection unit (included in the service kit) CE980-67901 1
4 Arm, waste toner, left RC2-7035-000CN 1
5 Cover, waste toner, 3 RC2-6963-000CN 1
6 Plate, arm reinforcement RC2-9649-000CN 1
7 Arm, waste toner, right RC2-7036-000CN 1
8 Spring, tension RU6-2831-000CN 1
9 Waste toner cover assembly (includes Residual Toner Full Sensor) RM1-6012-000CN 1
10 Cover, waste toner, 2 RC2-6962-000CN 1
11 Shutter, exhaust RC2-7010-000CN 1
12 Spring, compression RU6-2683-000CN 1
13 Guide, fuser AC cable RC2-6693-000CN 1
14 Guide, LVT cable RC2-6662-000CN 1
15 Clamp, edge RC2-6663-000CN 1
16 Gear, link worm RU6-0795-000CN 1
17 ITB guide rail assembly RM1-6019-000CN 1
18 Guide, slide RC2-7203-000CN 1
19 Slider, push RC2-7201-000CN 1
20 Lever, lift, 1 RC2-7199-000CN 1
21 Cover, main cross-member cable RC2-6650-000CN 1
22 Guide, main cross-member cable RC2-6600-000CN 1
23 Label, ITB set, RH RU5-8807-000CN 1
24 Rail, ITB guide RC2-7185-000CN 1
25 Label, ITB, RV RU5-8805-000CN 1
26 Rail, ITB guide, F3 RC2-7193-000CN 1
27 Guide, inside cable RC2-6589-000CN 1
28 ITB assembly (included in the service kit; includes transfer roller) CC522-67911 1
29 Fan, power supply RK2-2276-000CN 1
30 Holder, power supply fan RC2-7299-000CN 1
ENWW Internal components (6 of 9) 563
