Table 4-13 Internal components (7 of 9)
Ref Description Part number Qty
31 Duct, fan, 1 RC2-8388-000CN 1
32 Laser scanner assembly RM1-6122-070CN 1
33 Seal, toner supporter guide 1 RC2-7018-000CN 1
34 Toner feed assembly RM1-6040-000CN 1
35 Guide, laser RC2-6628-000CN 1
36 Holder, flat flexible cable RC2-6655-000CN 1
37 Cable assembly, flat-flexible RM1-6804-000CN 1
38 Seal, slide shutter RC3-1014-000CN 3
39 Sheet, slide seal RC3-1013-000CN 1
40 Label, ITB insert, FV RU5-8804-000CN 1
41 Label, ITB insert, FH RU5-8806-000CN 1
ENWW Internal components (7 of 9) 565
