Table 4-14 Internal components (8 of 9)
Ref Description Part number Qty
1 Holder, first power dispatching RC2-6680-000CN 1
2 Spring, contact RU6-2767-000CN 2
3 Spring, contact RU6-2768-000CN 2
4 Guide, cross-member cable, rear RC2-6588-000CN 1
5 Stopper, laser RC2-6646-000CN 1
6 Guide, cross-member cable, front RC2-6587-000CN 1
7 Spring, rod RC2-6611-000CN 1
8 Cover, cable, right rear RC2-8424-000CN 1
9 Lifter drive assembly RM1-6039-000CN 1
10 Auto close assembly RM1-6036-000CN 1
11 Holder, switch RC2-6666-000CN 1
12 Cable, switch RM1-6830-000CN 1
13 Low voltage power supply assembly, 110V RM1-6753-000CN 1
13 Low voltage power supply assembly, 220V RM1-6754-000CN 1
14 Guide, cable RC3-0684-000CN 1
15 Cable, low-voltage AC joint RM1-6811-000CN 1
16 Cable, low-voltage power supply RM1-6807-000CN 1
17 Cable, low-voltage power supply, test RM1-6813-000CN 1
18 Cable, left, high-voltage power supply to low-voltage power supply RM1-6833-000CN 1
ENWW Internal components (8 of 9) 567
