Table 4-15 Internal components (9 of 9)
Ref Description Part number Qty
1 Clamp, edge, D RC2-6674-000CN 1
2 Guide, cable, right RC2-6842-000CN 1
3 Guide, cable, upper RC2-6841-000CN 1
4 Cable, PNL-H-HI RM1-6849-000CN 1
5 Spacer, DC controller PCA VT2-5176-004CN 5
6 Guide, DC cont. support cable RC2-6665-000CN 1
7 Cable, primary transfer RM1-6822-000CN 1
8 Cable, rear RM1-6863-000CN 1
9 Formatter case RM1-6065-000CN 1
10 Plate, FFC protective RC2-9687-000CN 1
11 Holder, paper pick-up connector RC2-6638-000CN 1
12 Connector, 8-pin, paper-pick-up VS1-7514-008CN 1
13 Plate, box pillar RC2-6673-000CN 2
14 Guide, imaging HVT cable RC2-6661-000CN 1
15 Cover, imaging HVT cable RC2-6573-000CN 1
16 Cross-member, cover, left RC2-6760-000CN 2
17 Holder, formatter fan RC2-6648-000CN 1
18 Fan, formatter RK2-3301-000CN 1
19 Core, ring WE8-6639-000CN 1
ENWW Internal components (9 of 9) 569
