Table 4-21 1x500PF internal components
Ref Description Part number Qty
1 Switch, bottom (1x500PF) WC2-5512-000CN 1
2 Motor, pick-up (1x500PF) RK2-1331-000CN 1
3 Lifter drive assembly (1x500PF) RM1-3819-000CN 1
4 Cassette (1x500PF) CF235-67917 1
5 Paper pick-up assembly (1x500PF) RM1-6944-000CN 1
6 Paper feeder driver PCA (1x500PF) RM1-6987-000CN 1
8 Roller, feed, paper feeder (included in service kit) CE710-67908 2
9 Label, cassette number (1x500PF) 5851-5600 1
A03 Connector, 8P (1x500PF) VS1-7514-008CN 1
ENWW 1x500 paper feeder 581
