Table 4-24 3x500PF internal components
Ref Description Part number Qty
1 Motor, stepping, DC (3x500PF) RK2-1331-000CN 3
2 Rail, cassette, right (3x500PF) RL1-1390-000CN 3
3 Rail, cassette, left (3x500PF) RL1-1391-000CN 3
4 Cable, paper pick-up option (3x500PF) RM1-3575-000CN 3
5 Cable, multisensor (3x500PF) RM1-3647-000CN 3
6 Cable, door open switch (3x500PF) RM1-3651-000CN 1
7 Lifter drive assembly (3x500PF) RM1-3819-000CN 3
8 Cassette (3x500PF) CF235-67917 1
9 Paper pick-up assembly (3x500PF) RM1-6944-000CN 3
10 Feeder PCA (3x500PF) RM1-6989-000CN 1
11 Cable, engine interface (3x500PF) RM1-6991-000CN 1
12 Cable, PCA joint (3x500PF) RM1-6992-000CN 2
13 Switch, button (3x500PF) WC2-5512-000CN 1
14 Roller, pick-up (included in the service kit; 3x500PF) CC522-67909 1
16 Caster, double lock, front (3x500PF) RC1-9896-000CN 2
17 Caster, rear RC3-2994-000 1
18 Connector, 8P (3x500PF) VS1-7500-008CN 1
19 Label, cassette number (3x500PF) 5851-5600 1
ENWW 3x500 paper feeder 587
