Numerical parts list
Table 4-28 Numerical parts list
Part number Description Table and page
5851-5600 Label, cassette number (1x500PF)
1x500PF internal components
on page 581
5851-5600 Label, cassette number (3x500PF)
3x500PF internal components
on page 587
CC522-67906 Door, inner, service kit includes all labels
Internal components (1 of 9)
on page 553
CC522-67909 Roller, pick-up (included in the service kit; 3x500PF)
3x500PF internal components
on page 587
CC522-67911 ITB assembly (included in the service kit; includes transfer roller)
Internal components (6 of 9)
on page 563
CC522-67912 Roller, secondary transfer, T2 (included in the service kit)
Right door assembly
on page 551
CC522-67928 Roller, paper pick-up, Tray 1 (included in the service kit)
Right door assembly
on page 551
CC522-67928 Pick roller and separation pad, Tray 1 (included in the service kit)
Right door assembly
on page 551
CE707-67902 Cover, front assembly
External covers, panels, and
doors on page 549
CE707-67903 Paper pick-up assembly
Paper pick-up assembly
on page 573
CE707-67904 Fuser drive assembly
Internal components (3 of 9)
on page 557
CE707-67905 Main drive assembly, simplex model
Internal components (4 of 9)
on page 559
CE707-67906 DC Controller PCA (simplex model)
PCAs on page 577
CE707-67907 Inter connect board (ICB) PCA
PCAs on page 577
CE707-67912 Fuser assembly, 110V (included in service kit)
Internal components (3 of 9)
on page 557
CE707-67913 Fuser assembly, 220V (included in service kit)
Internal components (3 of 9)
on page 557
CE708-67901 Main drive assembly, duplex model
Internal components (4 of 9)
on page 559
CE708-67902 DC Controller PCA (duplex model)
PCAs on page 577
CE710-67907 Tray 2 replacement, gray
1x250 cassette on page 571
CE710-67908 Roller, feed, paper feeder (included in service kit)
1x500PF internal components
on page 581
CE710-69007 Tray 2 pickup and separation roller assembly (included in service kit)
Internal components (3 of 9)
on page 557
CE980-67901 Toner collection unit (included in the service kit)
Internal components (6 of 9)
on page 563
604 Chapter 4 Parts and diagrams ENWW
