Table 4-28 Numerical parts list (continued)
Part number Description Table and page
RM1-6807-000CN Cable, low-voltage power supply
Internal components (8 of 9)
on page 567
RM1-6811-000CN Cable, low-voltage AC joint
Internal components (8 of 9)
on page 567
RM1-6813-000CN Cable, low-voltage power supply, test
Internal components (8 of 9)
on page 567
RM1-6822-000CN Cable, primary transfer
Internal components (9 of 9)
on page 569
RM1-6830-000CN Cable, switch
Internal components (8 of 9)
on page 567
RM1-6833-000CN Cable, left, high-voltage power supply to low-voltage power supply
Internal components (8 of 9)
on page 567
RM1-6846-000CN Cable, feed joint, duplex model
Internal components (4 of 9)
on page 559
RM1-6849-000CN Cable, PNL-H-HI
Internal components (9 of 9)
on page 569
RM1-6863-000CN Cable, rear
Internal components (9 of 9)
on page 569
RM1-6867-000CN Cable, SB joint, low-voltage power supply, duplex model
Internal components (3 of 9)
on page 557
RM1-6944-000CN Paper pick-up assembly (1x500PF)
1x500PF internal components
on page 581
RM1-6944-000CN Paper pick-up assembly (3x500PF)
3x500PF internal components
on page 587
RM1-6946-000CN Right door assembly (1x500PF)
1x500PF external components
on page 579
RM1-6948-000CN Cover, right lower assembly (1x500PF)
1x500PF external components
on page 579
RM1-6949-000CN Cover, upper front assembly (1x500PF)
1x500PF external components
on page 579
RM1-6953-000CN Right door assembly (3x500PF)
3x500PF external components
on page 585
RM1-6958-000CN Front lower cover assembly (3x500PF)
3x500PF external components
on page 585
RM1-6987-000CN Paper feeder driver PCA (1x500PF)
1x500PF internal components
on page 581
RM1-6987-000CN Paper feeder driver PCA (1x500PF)
1x500PF PCA on page 583
RM1-6989-000CN Feeder PCA (3x500PF)
3x500PF internal components
on page 587
RM1-6989-000CN Feeder PCAs (3x500PF)
3x500PF PCAs on page 591
RM1-6991-000CN Cable, engine interface (3x500PF)
3x500PF internal components
on page 587
ENWW Numerical parts list 613
