Description Spare part number
●
For use with WSVGA display assembly 607112-001
Webcam module 577927-001
Display panel/webcam cable
●
For use in high-definition display assembly 577932-001
●
For use in WSVGA display assembly 577931-001
Display cable kit includes the following cables: 577933-001
●
WLAN antennas (2) with cables
●
Dual microphone with cable
●
WWAN antennas (2) with cables on select models
Display back cover (includes logo)
●
For use with touch screen, black 598457-001
●
For use with touch screen, red 598458-001
●
For use with touch screen, blue 598459-001
●
For use with non-touch screen, black 577928-001
●
For use with non-touch screen, red 606201-001
●
For use with non-touch screen, blue 606970-001
Before removing the display assembly, follow these steps:
1. Shut down the device. If you are unsure whether the device is off or in Hibernation, turn the
device on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the device.
3. Disconnect the power from the device by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the device.
4. Remove the battery (see
Battery on page 41).
5. If your device has WWAN capability, remove the SIM (see
SIM on page 42).
6. Remove the following components:
a. Keyboard (see
Keyboard on page 45)
b. Hard drive (see
Mass storage devices on page 52)
c. WLAN module (see
WLAN module on page 55)
d. Top cover (see
Top cover on page 59)
Component replacement procedures 69
