Specifications
H: 4.2 cm (1.64 inch), W: 44.3 cm (17.42 inch), D: 39 cm (15.4 inch)Dimensions
6.1 kg (13.45 lb)Weight
100–127/200–240 voltsAC voltage
1
2 A/1 AMaximum current
50/60 HzFrequency range
Operating: 5°C to 40°C (41°F to 122°F), Non-operating: -40°C to 65°C (-40°F to 149°F)Temperature
Operating: 15% to 80% at 40°C (104°F), Non-operating: 20% to 90% at 65°C (149°F)Relative humidity
nl
(non-condensing)
Operating: 2 km (6,500 ft), Non-operating: 4.6 km (15,000 ft)Maximum altitude
Noise Emission LwA=52 dB at virtual work space according to DIN 45635 T.19Acoustic
The 10/100/1000 Mbps RJ-45 twisted-pair ports are compatible with IEEE 802.3ab 1000Base-T,
IEEE 802.3u 100Base-TX, and IEEE 802.3 10Base-T standards.
Connectors
Complies with EN60950-1/IEC 60950-1, CSA 22.2 No. 60950-1, and UL 60950-1 standards.Safety
1
The controller automatically adjusts to any voltage between 100–127 and 200–240 volts at either 50 or 60 Hz.
