Table 1-1 Product components and their descriptions (continued)
Category Description
● 8192 MB (8192 MB × 1 or 4096 MB × 2)
● 4096 MB (4096 MB × 1) (available only with HP ThinPro)
Primary storage 128 GB, SATA-3, SS, TLC, M.2 (2280), NGFF, solid-state drive
Audio and video HP Bang & Olufsen Audio
Multi-array microphone (including rear-facing 3rd microphone)
Stereo speakers (2) (13 mm × 38 mm × 4 mm)
Webcam HD RGB 720p
Webcam HD RGB 720p + IR
Camera privacy cover
Supports WDR (Wide Dynamic Range)
Support for models without camera
RJ-45 (network) RTL8111EPH-CG (DASH)
The following support S3/S5 wake on LAN/HBMA (via out of band): HP USB-C Dock G4, HP
Thunderbolt Dock 120 W G2, HP USB-C Mini Dock, HP Elite USB-C Dock G5, and HP USB-C Universal
Dock G2
The following support S0/S3/S5 MAPT (via out of band): HP USB-C Dock G4, HP Thunderbolt Dock
120 W G2,, HP USB-C Mini Dock, HP Elite USB-C Dock G5, and HP USB-C Universal Dock G2
Wireless networking Bluetooth®
Bluetooth 5.0 support
Wireless local area network (WLAN)
Integrated WLAN options with dual antennas (M.2 2230 socket PCIe/USB):
● Intel Wireless-AC 9260 802.11ac 2 × 2 Wi-Fi + Bluetooth 5.0 (non-vPro, supporting Gigabit Wi-
Fi speeds)
Two WLAN antennas built into bottom of display assembly
Compatible with Wi-Fi CERTIFIED Miracast™-certied devices
Supports HP Connection Optimizer with data analytics
Supports WoWLAN S3
Supports HP LAN-Wireless Protection (WLAN/LAN/WWAN switching)
Supports Static BIOS SAR
Supports Turbo Lite Wi-Fi
Supports Fast PCIe Error Identication
Near-Field Communication (NFC)
NXP NPC300 Near Field Communication Module (NXP NPC300 I2C 10 mm x 17 mm)
NFC antenna
Support for models without NFC
2 Chapter 1 Product description
