HP mt45 User Manual

1 Product description
Table 1-1 Product components and their descriptions
Category Description
Product Name HP mt45 Mobile Thin Client
Processors AMD® Ryzen™ 3 PRO 3300U Mobile Processor with Radeon™ Vega Graphics
Graphics Internal graphics
Radeon Vega Graphics
Supports HD decode, DX12, HDMI 2.0, HDCP 2.2 via HDMI or DisplayPort™ up to 4K @ 60 Hz
Supports independent displays through docking stations as follows:
● HP UltraSlim Docking Station–maximum resolution = dual 2K @ 60 Hz, single 4K @ 60 Hz,
1920 × 1200 @ 60 Hz (VGA); dock connectors: 1 VGA, 2 DisplayPorts
● HP USB-C Dock G4–maximum resolution = dual 2K @ 60 Hz, single 4K @ 60 Hz; dock
connectors: 1 HDMI, 2 DisplayPorts
● HP Elite USB-C Dock G5–maximum resolution = dual 2K @ 60 Hz, single 4K @ 60 Hz; dock
connectors: 1 HDMI, 2 DisplayPorts
● HP USB-C/A Universal Dock G2–maximum resolution = three 4K @ 60 Hz via USB Type-C, dual
4K @ 60 Hz; dock connectors via USB Type-A: 1 HDMI, 2 DisplayPorts
● HP Thunderbolt Dock–maximum resolution = dual 2K @ 60 Hz, single 4K @ 60 Hz, 1600 × 900
(VGA); dock connectors: 1 HDMI, 2 DisplayPorts, 1 VGA
Panel Supports privacy lter and narrow bezel
35.6 cm (14.0 in), UWVA, non-touch
Full high-denition (FHD) (1920 × 1080), antiglare, 250 nits, 45% CG, eDP, slim, without camera
FHD (1920 × 1080), antiglare, 250 nits, 45% CG, eDP, slim, with HD camera
FHD (1920 × 1080), antiglare, 250 nits, 45% CG, eDP, slim, with HD + IR camera
FHD (1920 × 1080), antiglare, 250 nits, 45% CG, eDP, slim, without camera, with WWAN
FHD (1920 × 1080), antiglare, 250 nits, 45% CG, eDP, slim, with HD camera, with WWAN
FHD (1920 × 1080), antiglare, 250 nits, 45% CG, eDP, slim, with HD + IR camera, with WWAN
FHD (1920 × 1080), antiglare, 1000 nits, 72% CG, eDP + PSR, at, Ambient Light Sensor, privacy,
with HD + IR camera, with WWAN
35.6 cm (14.0 in), UWVA, touch screen
FHD (1920 × 1080), antiglare, 250 nits, 45% CG, eDP, slim, with HD + IR camera, with WWAN, TOP
Memory Two memory module slots
Memory is customer accessible/upgradeable
DDR4-2400 dual channel support
Supports up to 8 GB of system RAM in the following congurations:
1

HP mt45 Specifications

General

Battery	HP Long Life 3-cell, 50 Wh Li-ion
Processor	AMD Ryzen 3 PRO 3300U
Graphics	AMD Radeon Vega Graphics
Display	14" diagonal FHD IPS anti-glare WLED-backlit (1920 x 1080)
Memory	8 GB DDR4-2400 SDRAM
Ports	1 USB 3.1 Type-C, 2 USB 3.1 Gen 1, 1 HDMI 2.0, 1 RJ-45, 1 headphone/microphone combo
Wireless	Intel Dual Band Wireless-AC 9260 802.11a/b/g/n/ac (2x2) Wi-Fi and Bluetooth 5 Combo
Operating System	Windows 10 IoT Enterprise
