10 Diagnostics and troubleshooting
LEDs
Table 10-1 Power and IDE Flash Activity LEDs
LED Status
Power LED O When the unit is plugged into the wall socket and the Power LED is o, the unit is powered o.
However, the network can trigger a Wake On LAN event in order to perform management functions.
Power LED On Displays during boot sequence and while the unit is on. During boot sequence, hardware initialization is
processed and startup tests are performed on the following:
● Processor initialization
● Memory detection and initialization
● Video detection and initialization
NOTE: If one of the tests fails, the unit will simply stop, but the LED will stay on. If the video test fails,
the unit beeps. There are no messages sent to video for any of these failed tests.
NOTE: After the video subsystem is initialized, anything that fails will have an error message.
NOTE: RJ-45 LEDs are located inside the RJ-45 connector on the top, rear panel of the thin client. The LEDs are visible when the
connector is installed. Blinking green indicates network activity, and amber indicates a 100MB speed connection.
IDE LED is O When the unit is powered on and the ash activity light is o, then there is no access to the system
ash.
IDE LED blinks white Indicates the system is accessing the internal IDE ash.
86 Chapter 10 Diagnostics and troubleshooting
