Table 2-1 Right-side components and their descriptions (continued)
Component Description
(5) RJ-45 (network) jack/status lights Connects a network cable.
● Green (left): The network is connected.
● Amber (right): Activity is occurring on the network.
(6) Docking connector Connects an optional docking device.
(7) USB Type-C SuperSpeed port and DisplayPort
connector
When the computer is on, connects and charges most USB
devices that have a Type-C connector, such as a cell phone,
camera, activity tracker, or smartwatch, and provides high-
speed data transfer.
NOTE: Cables and/or adapters (purchased separately) may be
required.
– and –
Connects a DisplayPort device that has a USB Type-C connector,
providing display output.
(8) Power connector Connects an AC adapter.
(9) Battery light When AC power is connected:
● White: The battery charge is greater than 90 percent.
● Amber: The battery charge is from 0 to 90 percent.
● O: The battery is not charging.
When AC power is disconnected (battery not charging):
● Blinking amber: The battery has reached a low battery
level. When the battery has reached a critical battery level,
the battery light begins blinking rapidly.
6 Chapter 2 Components
