Table 3-1 Computer major components and their descriptions
Item Component Spare part number
Display assembly
Display assemblies are available as spare parts at the subcomponent level only. For more
display assembly spare part information, see Display assembly subcomponents
on page 22.
(1) Non-touch display not available as a whole
assembly
(2) Touch display not available as a whole
assembly
(3) Keyboard (backlit)
For a list of keyboard country codes, see Keyboard on page 40.
L14377-xx1
(4) Top cover (includes power button) L62293-001
(5) RJ-45 board with bracket L14386-001
(6) Touchpad
For use in models without an NFC module L62731-001
For use in models with an NFC module L62732-001
(7) Touchpad button board L18311-001
(8) RTC battery L17255-001
(9) Power button board (includes cable) L62738-001
(10) USB board (includes bracket and cable) L62735-001
(11) USB board bracket (included in the Bracket Kit) L62737-001
(12) Fingerprint reader assembly (includes cable)
NOTE: The ngerprint reader bracket is included in the Bracket Kit, spare part number
L62737-001.
L62741-001
(13) NFC module (includes antenna and touchpad foam) L14385-001
(14) Speakers (includes cable) L62736-001
(15) Smart card reader board
NOTE: The smart card reader pass-thru board (for use in models without a smart card) is
available as spare part number L62743-001.
L62733-001
(16) System board (includes AMD Ryzen 3 PRO 3300U Mobile Processor with Radeon Vega
Graphics and replacement thermal material)
L62972-301
(17) Fan L62739-001
(18) Heat sink L68813-001
(19) Memory module (DDR-2666)
4 GB L10598-850
(20) WLAN/Bluetooth combo card
Intel Wireless-AC 9260 802.11ac 2 × 2 Wi-Fi + Bluetooth 5.0 (non-vPro, supporting Gigabit
Wi-Fi speeds)
920687-001
Computer major components 21
