ENWW Clearing jams 187
Clearing jams in the ADF
If the print media is jammed in the all-in-one, use the following instructions below to clear the
jam. See Tips for avoiding jams for information about how to avoid jams.
To clear a jam in the ADF
1 If a page is sticking out of an area, gently try to remove it without tearing the page. If you
feel resistance, continue with the following steps.
2 Remove the ADF input tray and open the ADF cover.
3 Remove the jam cleanout part. Using both hands, lift up on the two handles until the part
unsnaps. Rotate and lift out the cleanout and set it aside.
4 While lifting the green lever, rotate the pick mechanism until it stays open.
5 Gentry try to remove the page without tearing it. If you feel resistance, continue with the
next step.
6 Open the ADF and gently loosen the media by using both hands.
7 When the media is free, gently pull it out.
