HP OMEN 15 User Manual

Item Component Spare part number
Includes 8-GB of system memory and 4 GB of discrete graphics memory for use in models
with Windows 8.1 Standard
788616-501
Includes 8-GB of system memory and 4 GB of discrete graphics memory for use in models
with Windows 8.1 Professional
788616-601
Includes 8-GB of system memory and 2 GB of discrete graphics memory for use in models
without the Windows operating system
788614-001
Includes 8-GB of system memory and 2 GB of discrete graphics memory for use in models
with Windows 8.1 Standard
788614-501
Includes 8-GB of system memory and 2 GB of discrete graphics memory for use in models
with Windows 8.1 Professional
788614-601
(8) Power connector cable (includes cable, bracket, and screws) 788599-001
(9) Battery, 4-cell, 58-Wh, 3.82-Ah, Li-ion 778978-006
(10) WLAN modules:
Intel Wireless 7260BN 802.11 bgn 2x2 WiFi + BT 4.0 Combo Adapter 784640-006
Intel Dual Band Wireless-AC 7260(non v-Pro) 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter 784645-006
(11) Solid-state drive (SSD), M.2
512 GB, MLC, M.2.2260, PCIe 788613-001
256 GB, MLC, M.2.2280, PCIe 788612-001
128 GB, TLC, M.2.2280, SATA 788611-001
(12) Speaker Kit (includes left and right speakers) 788610-001
(13) Base enclosure (includes rubber feet) 788598-001
Miscellaneous parts
Component Spare part number
120-W HP Smart AC adapter (PFC, 4.5-mm) 710415-001
HP RJ45-to-USB adapter 539614-001
HP HDMI-to-VGA adapter 701943-001
Screw Kit 788609-001
Power cord (3-pin, black, 1.00-m):
For use in Australia 490371-011
For use in Denmark 490371-081
For use in Europe 490371-021
For use in Japan 490371-291
For use in North America 490371-001
For use in the People’s Republic of China 490371-AA1
14 Chapter 3 Illustrated parts catalog

HP OMEN 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Market positioning	Gaming
Built-in microphone	Yes
Speakers manufacturer	Bang & Olufsen
Number of built-in speakers	2
Display surface	Matt
Display diagonal	15.6 \
Native aspect ratio	16:9
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-6700HQ
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6700 Mobile series
Processor socket	BGA 1440
Processor threads	8
Processor codename	Skylake
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® HM170
Pointing device	Touchpad
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 8 GB
HDD speed	7200 RPM
HDD capacity	1000 GB
SSD capacity	256 GB
HDD interface	SATA
SSD interface	PCI Express
Storage media	HDD+SSD
SSD form factor	M.2
Total storage capacity	1256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Processor code	SR2FQ
Processor ARK ID	88967
Processor package size	42 x 28 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
On-board graphics card ID	0x191B
Discrete graphics card model	NVIDIA® GeForce® GTX 965M
On-board graphics card model	Intel® HD Graphics 530
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card memory	2.005 GB
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Battery capacity	61.5 Wh
Battery life (max)	11 h
Number of battery cells	3
AC adapter power	120 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V
Cable lock slot type	Kensington
WWAN	Not installed
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	253 mm
Width	382 mm
Height	24.5 mm
Weight	2090 g
