Component Spare part number
For use in South Korea 490371-AD1
For use in Switzerland 490371-111
For use in the United Kingdom and Singapore 490371-031
Display assembly subcomponents
Item Component Spare part number
(1) Display Panel Kit (includes bezel, touch glass, and panel)
NOTE: Must be assembled in a clean room.
788608-001
(2) Webcam/microphone module 788620-001
(3) Touch control board 788606-001
(4) Display Hinge Kit (includes left/right hinges, LVDS cable, touch control cable, and left and right antennas)
NOTE: The display hinge kit is spared with the display enclosure (788597-001).
(5) Display enclosure (includes the display hinge kit)
NOTE: The display enclosure spare part kit also includes the display hinge kit with left/
right hinges, LVDS cable, touch control cable, and left and right antennas.
788597-001
Display assembly subcomponents 15
