HP OMEN 15 User Manual

Sequential part number listing
Spare part number Description
490371-001 Power cord for use in North America (3-pin, black, 1.83-m)
490371-011 Power cord for use in Australia (3-pin, black, 1.83-m)
490371-021 Power cord for use in Europe (3-pin, black, 1.83-m)
490371-031 Power cord for use in the United Kingdom and Singapore (3-pin, black, 1.83-m)
490371-081 Power cord for use in Denmark (3-pin, black, 1.83-m)
490371-111 Power cord for use in Switzerland (3-pin, black, 1.83-m)
490371-291 Power cord for use in Japan (3-pin, black, 1.83-m)
490371-AA1 Power cord for use in the People’s Republic of China (3-pin, black, 1.83-m)
490371-AD1 Power cord for use in South Korea (3-pin, black, 1.83-m)
539614-001 HP RJ-45-to-USB adapter
701943-001 HP HDMI-to-VGA adapter
710415-001 120-W HP Smart AC adapter (PFC, 4.5-mm)
778978-006 4-cell, 58-Wh, 3.82-Ah, Li-ion battery
784640-006 Intel Wireless 7260BN 802.11 bgn 2x2 WiFi + BT 4.0 Combo Adapter
784645-006 Intel Dual Band Wireless-AC 7260(non v-Pro) 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter
788597-001 Display enclosure (includes the display hinge kit with left/right hinges, LVDS cable, touch control cable,
and left and right antennas)
788598-001 Base enclosure (includes rubber feet)
788599-001 Power connector cable (includes cable, bracket, and screws)
788600-001 Heat sink
788603-001 Keyboard/top cover in purple finish for use in the United States (includes top cover, keyboard, keyboard
support bracket, and screws)
788603-031 Keyboard/top cover in purple finish for use in the United Kingdom and Singapore (includes top cover,
keyboard, keyboard support bracket, and screws)
788603-041 Keyboard/top cover in purple finish for use in the Germany (includes top cover, keyboard, keyboard
support bracket, and screws)
788603-051 Keyboard/top cover for use in France (includes top cover, keyboard, keyboard support bracket, and
screws)
788603-061 Keyboard/top cover for use in Italy (includes top cover, keyboard, keyboard support bracket, and screws)
788603-071 Keyboard/top cover for use in Spain (includes top cover, keyboard, keyboard support bracket, and screws)
788603-131 Keyboard/top cover for use in Portugal (includes top cover, keyboard, keyboard support bracket, and
screws)
788603-141 Keyboard/top cover for use in Turkey (includes top cover, keyboard, keyboard support bracket, and
screws)
788603-151 Keyboard/top cover for use in Greece (includes top cover, keyboard, keyboard support bracket, and
screws)
16 Chapter 3 Illustrated parts catalog

HP OMEN 15 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Black
Country of origin	China
Market positioning	Gaming
Built-in microphone	Yes
Speakers manufacturer	Bang & Olufsen
Number of built-in speakers	2
Display surface	Matt
Display diagonal	15.6 \
Native aspect ratio	16:9
Bus type	DMI3
Stepping	R0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-6700HQ
System bus rate	8 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-6700 Mobile series
Processor socket	BGA 1440
Processor threads	8
Processor codename	Skylake
Processor frequency	2.6 GHz
Processor cache type	Smart Cache
Configurable TDP-down	35 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® HM170
Pointing device	Touchpad
Memory slots	2x SO-DIMM
Internal memory	16 GB
Memory clock speed	2133 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR4-SDRAM
Memory layout (slots x size)	2 x 8 GB
HDD speed	7200 RPM
HDD capacity	1000 GB
SSD capacity	256 GB
HDD interface	SATA
SSD interface	PCI Express
Storage media	HDD+SSD
SSD form factor	M.2
Total storage capacity	1256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Processor code	SR2FQ
Processor ARK ID	88967
Processor package size	42 x 28 mm
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
On-board graphics card ID	0x191B
Discrete graphics card model	NVIDIA® GeForce® GTX 965M
On-board graphics card model	Intel® HD Graphics 530
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card memory	2.005 GB
Maximum on-board graphics card memory	1.7 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1050 MHz
Battery capacity	61.5 Wh
Battery life (max)	11 h
Number of battery cells	3
AC adapter power	120 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output voltage	19 V
Cable lock slot type	Kensington
WWAN	Not installed
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	253 mm
Width	382 mm
Height	24.5 mm
Weight	2090 g
