HP OMEN 880 - Page 3

EL-MF877-00 Page 3
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Figure1 Press the latch button on rear side
Figure2 Remove the access side cover L
Figure3 Remove internal lighting module by 3 screws
Figure4 Release GFX holder screws and cables PWR
then remove GFX card from the chassis inside
Figure5 Unplug the cables of fan and pump
Figure6 Release the CPU Pump and radiator screw to
remove CPU LC
