Figure7 Unplug all cables connector from PCA.
Figure8 Release 8 PCS screws from PCA
Figure9 Remove MB cap and uninstall the MB screws to
take off PCA from the chassis inside
Figure10 Push the memory hook son both sides and then
pick up the memory
Figure11 Rotate the handle and open it up and remove
the CPU from board
Figure12 Remove the battery from the PCA
