Item Component Spare part number
(5) USB board cable 856729-001
(6) RTC battery 741976-001
(7) Power connector (includes cable) 858021-001
(8) Power button board 858974-001
Power button board cable 858966-001
(9) SSD
Generic SSD 128 GB 2280 M2 SATA-3 Value TL 827560-027
Generic SSD 256 GB 2280 M2 PCIe 3x4SS NVMe TLC TL 847109-008
Generic SSD 512 GB 2280 M2 PCIe 3x4SS NVMe TLC TL, not for products with AMD Radeon
hybrid graphics
847110-007
(10) System board (see System board on page 53)
(11) Memory
For use with products with Intel 6th generation processors:
2 GB 2133 MHz 1.2v DDR4 shared, not for products with AMD Radeon hybrid graphics 851379-005
4 GB 2133 MHz 1.2v DDR4 shared 820569-005
8 GB 2133 MHz 1.2v DDR4 shared 820570-005
For use with products with Intel 7th generation processors:
2 GB 2400 MHz 1.2v DDR4 shared 864271-855
4 GB 2400 MHz 1.2v DDR4 shared 862397-855
8 GB 2400 MHz 1.2v DDR4 shared 862398-855
(12) WLAN module, Intel Dual Band Wireless-AC 7265 793840-005
(13) Heat sink
Products with NVIDIA GeForce GTX 950M/960M/965M hybrid graphics 856668-001
Products with AMD Radeon hybrid graphics 901922-001
Products with NVIDIA GeForce GTX 1050/1050Ti hybrid graphics 920563-001
(14) Heat sink for CPU and graphics 725625-001
(15) USB board 858975-001
(16) Hard drive
1 TB 7200 RPM SATA RAW 9.5 mm 766644-005
2 TB 5400 RPM SATA RAW 7 mm, not available for products with AMD Radeon hybrid
graphics
912487-855
Hard drive cable 858969-001
(17) Hard drive brackets 913937-001
(18) Battery cable 858968-001
(19) Fan, the same spare part number can be used to replace either the right fan or the left fan 858970-001
22 Chapter 3 Illustrated parts catalog
