TouchPad
Description Spare part number
TouchPad board
●
Shadow Mesh 860364-001
●
Hybrid Green 860330-001
TouchPad cable 858967-001
Top cover with TouchPad in Black with Hybrid Green, and backlit keyboard 905118-001
Top cover with TouchPad in Black with Shadow Mesh, and backlit keyboard in Dragon Red 859735-XXX
For use in country
or region
Spare part
number
For use in country
or region
Spare part
number
For use in country
or region
Spare part
number
Belgium -A41 Israel -BB1 South Korea -AD1
Bulgaria -261 Italy -061 Spain -071
Canada -DB1 Japan -291 Switzerland -BG1
Czech Republic
and Slovakia
-FL1 Latin America -161 Taiwan -AB1
Denmark, Norway,
Finland, and Sweden
-DH1 The Netherlands -B31 Thailand -281
France -051 Portugal -131 Turkey -141
Germany -041 Romania -271 United Kingdom -031
Greece -151 Russia -251 United States -001
Hungary -211 Saudi Arabia -171
India -002 Slovenia -BA1
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
Before removing the TouchPad, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the base enclosure (see Base enclosure on page 32).
5. Remove the battery (see Battery on page 34).
Remove the TouchPad:
1. Remove the 3 Phillips 2.0x2.0 screws (1), and then lift the TouchPad bracket (2) to remove it.
58 Chapter 5 Removal and replacement procedures for authorized service provider parts
