Display panel
Description Spare part number
Bezel
For products with an HD camera 856725-001
For products with a 3D camera 856726-001
Display panel
15.6" FHD AG UWVA 220 eDP, Slim 752920-014
15.6" UHD AG UWVA 300 eDPU Slim 842484-004
15.6" 1920x1080 AG UWVA 220 eDPU Slim (limited to China localization only) 915613-001
Hinge assembly 856741-001
Hinge cap assembly 859737-001
Display cable
FHD display cable for products with an HD camera 856733-001
FHD display cable for products with a 3D camera 856734-001
UHD display cable for products with an HD camera 856735-001
UHD display cable for products with a 3D camera 856736-001
WLAN antenna 856923-001
Back cover
In Hybrid Green nish, with antenna 905115-001
In Shadow Mesh nish, with antenna, for products with HD camera 856715-001
In Shadow Mesh nish, with antenna, for products with 3D camera 856718-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
Before removing the display assembly, follow these steps:
1. Shut down the computer.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by rst unplugging the power cord from the AC outlet and then
unplugging the AC adapter from the computer.
4. Remove the base enclosure (see Base enclosure on page 32).
5. Disconnect the battery (see Battery on page 34), and then remove the following components:
▲
Display assembly (see Display assembly on page 37).
Remove the display panel:
1. Use a thin plastic tool to disengage the bezel starting on the top edge (1). Continue on the left and right
edges (2) and then bottom edge (3), and then lift the display bezel (4) to remove it.
60 Chapter 5 Removal and replacement procedures for authorized service provider parts
