4. Remove the base enclosure (see Base enclosure on page 32).
5. Disconnect the battery (see Battery on page 34).
If you are replacing a memory module, remove the existing memory module:
1. Lift the clear lm covering the memory module.
2. Pull away the retention clips (1) on each side of the memory module.
The memory module tilts up.
3. Grasp the edge of the memory module (2), and then gently pull the memory module out of the memory
module slot.
CAUTION: To prevent damage to the memory module, hold the memory module by the edges only. Do
not touch the components on the memory module.
To protect a memory module after removal, place it in an electrostatic-safe container.
Reverse this procedure to install a memory module.
Component replacement procedures 43
