Preparing the Monitor for Wall-Mounting
NOTE: This apparatus is intended to be supported by UL or CSA Listed wall mount bracket.
To attach the monitor to a mounting fixture:
1. Set the monitor screen face down on a flat, soft, protected table or desk surface with the support
column overhanging the edge.
2. If the center column and base are attached to the monitor, pinch together the two release tabs
on the bottom of the base (1) and pull the base off the center column (2). Then press the button
on the rear of the center column (3) and slide the center column off the monitor support column
(4).
Figure 2-2 Removing the Monitor Center Column and Base
3. Remove the two screws that attach the support column to the monitor (1), then slide the support
column back and remove it from the monitor (2).
Figure 2-3 Removing the Monitor Support Column
4 Chapter 2 Setting Up the Monitor ENWW
