2 Setting Up the Monitor
You can install the monitor on a desktop or mount it on a mounting fixture such as a wall mount or
swing arm. Be sure to place the monitor in a convenient, well- ventilated location. Connect the
monitor cables after you have installed the monitor.
To set up the monitor, ensure that the power is turned off to the monitor and all attached devices,
then follow the instructions below for your configuration.
Preparing the Monitor for Desktop Use
To assemble the monitor for desktop use:
1. Set the monitor screen face down on a flat, soft, protected table or desk surface with the support
column overhanging the edge.
2. Align the center column with the base and push the center column onto the base (1). Then align
the monitor support column with the center column and push the monitor all the way onto the
center column (2) until it snaps securely in place.
Figure 2-1 Installing the Monitor Center Column and Base
3. Lift the monitor to an upright position and place on a flat, stable surface.
ENWW Preparing the Monitor for Desktop Use 3
