HP Pavilion 11 x360 PC

3. To remove the display hinge covers:
NOTE: The display hinge covers are available using spare part number 758847-001 for red models
and 759503-001 for silver models.
a. Separate the top hinge cover by prying and rotating it off (1).
b. Remove the four Phillips PM2.5×5.0 screws (2) that secure the bottom hinge cover to the display.
c. Remove the bottom display hinge cover from the display (3).
4. To remove the display cable:
NOTE: The display cable is available using spare part number 761350-001.
a. Disconnect the end of the display cable from the small connector at the bottom of the display
panel (1).
b. Disconnect the display cable from the large connector on the bottom of the display panel (2).
Component replacement procedures 57
