c. Pry from the side to separate the enclosure from the display (3).
2. To remove the webcam module:
NOTE: The webcam is available using spare part number 758848-001.
a. Lift the webcam module (1) enough to gain access to the cable.
b. Disconnect the cable (2) from the module.
56 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
