f. Hard drive (see Hard drive on page 71)
g. System board (see
System board on page 80)
5. Remove the display panel (see
Display panel on page 59).
6. Remove the display assembly (see
Display assembly on page 98).
Remove the display assembly subcomponents:
1. If it is necessary to replace the webcamera/microphone module:
a. Disconnect the webcamera/microphone module cable (1) from the webcamera/microphone
module. (The webcamera/microphone module cable is part of the display panel cable.)
b. Detach the webcamera/microphone module (2) from the display back cover.)
2. If it is necessary to replace the hinges:
a. Remove the two top screws (1) and two bottom screws (2) from the display hinges.
b. Remove the display hinge covers (2).
102 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts

HP Pavilion 14 Specifications

General

Form factor	Clamshell
Product type	Laptop
Product color	Red
Country of origin	China
Processor cache	2 MB
Processor cores	4
Processor model	A8-7410
Processor family	AMD A8
Processor socket	Socket FT3b
Processor frequency	2.2 GHz
Processor cache type	L2
Processor manufacturer	AMD
Processor boost frequency	2.5 GHz
Internal memory	8 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3L-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	1000 GB
Compatible memory cards	SD
Panel type	SVA
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon R5
Number of built-in speakers	2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Ethernet LAN data rates	10, 100 Mbit/s
USB 2.0 ports quantity	1
VGA (D-Sub) ports quantity	0
Sustainability certificates	EPEAT Silver, ENERGY STAR
Cable lock slot type	Kensington
AC adapter power	45 W
Battery capacity	41 Wh
Number of battery cells	3
Bundled software	HP ePrint HP Games Powered by WildTangent HP Support Assistant software included McAfee LiveSafe Netflix Dropbox CyberLink PowerDirector TripAdvisor
Operating system architecture	64-bit
Pointing device	Touchpad

Weight and Dimensions

Depth	224 mm
Width	338 mm
Height	19.5 mm
Weight	1780 g
