2. Reset the battery lock latch (2) to the locked position.
Service door
Description Spare part number
Service door is available with the Plastics Kit. 734419-001
1. Using a small Phillips screwdriver, loosen the service door screw (1).
2. Lift the door (2).
3. Slide the service door (3) forward to remove.
50 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
