3. Close the display and turn the computer upside down.
4. Remove the 8 Phillips M2.5×6.5 screws from the bottom of the computer.
5. Turn the computer over and open the display.
6. Gently pull on the right upper corner (1) and lift around the edges of the top cover (2). Lift to
remove the top cover (3).
Component replacement procedures
69
