e. Keyboard (see Keyboard on page 62)
f. Top cover (see
Top cover on page 67)
Remove the optical drive connector cable:
1. Disconnect the optical drive connector cable (1) from the system board.
2. Release the optical drive connector cable from the clip (2) built into the base enclosure.
3. Remove the optical drive connector cable.
Reverse this procedure to install the optical drive connector cable.
Component replacement procedures
79
