Item Component Spare part
number
(14) Power connector cable 809295-001
(15) Heat sink assembly (includes replacement thermal materials):
For use in models with discrete AMD Radeon R7 M360 (Meso-XT) graphics 806760-001
For use in models with discrete graphics 809105-001
For use in models with UMA graphics AMD Radeon R5 806759-001
For use in models with UMA AMD Radeon R6 graphics 809104-001
(16) Fan 806747-001
(17) RTC battery 811080-001
(18) Hard drive (does not include bracket):
2-TB, 5400-rpm, 2.5-inch 801808-005
1-TB, 5400-rpm, 2.5-inch, hybrid 8 GB SSD 731999-005
1-TB, 5400-rpm, 2.5-inch 778192-005
750 GB, 5400 rpm hard drive, 2.5 inch 778190-005
500-GB, 5400-rpm, 2.5 inch 778186-005
(19) Hard drive bracket 809296-001
(20) DVD+/-RW Double-Layer SuperMulti Drive
For use in natural silver models 809304-001
For use in blizzard white models 809305-001
For use in cobalt blue models 809307-001
For use in peachy pink models 809308-001
For use in violet purple models 809309-001
For use in sunset red models 809306-001
For use in sparkling black models 810950-001
(21) Battery (4-cell, 41-Whr, 2.8-Ah Li-ion) 800049-001
(22) Bottom cover
For use in violet purple models 809290-001
For use in sunset red models 809286-001
For use in blizzard white models 809287-001
For use in cobalt blue models 809288-001
For use in natural silver models 809285-001
For use in peachy pink models 809289-001
For use in sparkling black models 810949–001
Base enclosure hinge caps (not pictured), (left and right) 809312-001
Rubber screw covers (not pictured) 809314-001
18 Chapter 3 Illustrated parts catalog
