Rear component
Component Description
Vent Enables airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
Right-side components
Item Component Function
(1)
Optical drive Reads optical discs, and, on select models, also writes to
optical discs.
(2)
USB ports Connect optional USB devices.
(3)
RJ-11 (modem) jack Connects a modem cable.
(4)
Power connector Connects an AC adapter.
16 Chapter 2 External component identification
