3–8 Maintenance and Service Guide
Illustrated parts catalog
(10) Bluetooth module cable
■ For use in dv3-2000 models 531811-001
■ For use in dv3-2300 models 591417-001
(11) Audio board (includes cable)
■ For use in dv3-2000 models 531812-001
■ For use in dv3-2300 models 591429-001
(12) USB board (includes cable) 531809-001
(13) Power connector and cable 531810-001
(14) System board for use only in dv3-2000 models (includes replacement thermal material):
■ For use only with computer models equipped with graphics subsystems with
discrete memory without touch screen displays
530780-002
■ For use only with computer models equipped with graphics subsystems with
UMA memory without touch screen displays
530781-001
■ For use only with computer models equipped with graphics subsystems with
discrete memory with touch screen displays
576795-001
■ For use only with computer models equipped with graphics subsystems with
UMA memory with touch screen displays
576796-001
System board for use only in dv3-2300 models (includes replacement thermal material):
■ For use only with computer models equipped with graphics subsystems with
UMA memory
591412-001
■ For use only with computer models equipped with graphics subsystems with
discrete memory
591413-001
(15) Processors (include replacement thermal material):
Intel Core 2 Duo processors for use only in dv3-2000 models:
■ T9900 3.06-GHz processor (6-MB L2 cache, 1066-MHz FSB) 570434-001
■ T9800 2.93-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507951-001
■ T9600 2.80-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507952-001
■ T9550 2.66-GHz processor (6-MB L2 cache, 1066-MHz FSB) 507953-001
■ P8800 2.66-GHz processor (3-MB L2 cache, 1066-MHz FSB) 570036-001
■ P8700 2.53-GHz processor (3-MB L2 cache, 1066-MHz FSB) 507960-001
■ P8600 2.40-GHz processor (3-MB L2 cache, 1066-MHz FSB) 507963-001
■ P7550 2.26-GHz processor (3-MB L2 cache, 1066-MHz FSB) 573076-001
■ T6600 2.20-GHz processor (6-MB L2 cache, 1066-MHz FSB) 513593-001
■ P7450 2.13-GHz processor (3-MB L2 cache, 1066-MHz FSB) 507965-001
■ T6500 2.10-GHz processor (6-MB L2 cache, 1066-MHz FSB) 572928-001
■ T6400 2.06-GHz processor (6-MB L2 cache, 1066-MHz FSB) 513592-001
■ P7350 2.00-GHz processor (3-MB L2 cache, 1066-MHz FSB) 507967-001
Continued
Item Description Spare Part Number
