3. Unplug the power cord from the AC outlet.
4. Turn the computer upside down on a flat surface.
5. Remove the battery from the computer.
NOTE: For more information, refer to the section Inserting or removing the battery on page 29.
6. Remove the hard drive cover:
a. Slide the battery release latch (1) to loosen the hard drive cover.
b. Pull away the hard drive cover (2).
7. If you are replacing a memory module, remove the existing memory module:
a. Pull away the retention clips (1) on each side of the memory module.
The memory module tilts up.
34 Chapter 5 Maintenance
