Phillips PM2.5×5.5 captive screw
Color Quantity Length Thread Head diameter
Black 6 5.5 mm 2.5 mm 4.4 mm
Where used:
(1) Three captive screws that secure the memory module compartment cover to the computer (screws
are secured by C-clips)
(2) Two captive screws that secure the hard drive bay cover to the computer (screws are secured by C-
clips)
134 Chapter 7 Screw listing
