Processor
NOTE: The processor spare part kit includes thermal material.
Description Spare part number
Intel Core2 Duo T9800 2.93 GHz with 6-MB L2 cache and 1066-MHz FSB 507951-001
Intel Core2 Duo T9600 2.80 GHz with 6-MB L2 cache and 1066-MHz FSB 507955-001
Intel Core2 Duo T9550 2.66 GHz with 6-MB L2 cache and 1066-MHz FSB 507953-001
Intel Core2 Duo T9400 2.53 GHz with 6-MB L2 cache and 1066-MHz FSB 507954–001
Intel Core2 Duo T6600 2.20 GHz with 2-MB L2 cache and 800-MHz FSB 513593-001
Intel Core2 Duo T6400 2.00 GHz with 2-MB L2 cache and 800-MHz FSB 513592-001
Intel Core2 Duo T5800 2.00 GHz with 2-MB L2 cache and 800-MHz FSB 515040-001
Intel Pentium Dual-Core T4200 2.00 GHz with 1-MB L2 cache and 800-MHz FSB 513599-001
Intel Pentium Dual-Core T3400 2.16 GHz with 1-MB L2 cache and 1066-MHz FSB 509549–001
Intel Core Duo P8700 2.53 GHz with 3-MB L2 cache and 1066-MHz FSB 507960-001
Intel Core Duo P8600 2.40 GHz with 3-MB L2 cache and 1066-MHz FSB 507961-001
Intel Core Duo P8400 2.26 GHz with 3-MB L2 cache and 1066-MHz FSB 507962-001
Intel Core Duo P7450 2.13 GHz with 3-MB L2 cache and 1066-MHz FSB 507122-001
Intel Celeron T1600 1.66 GHz with 1-MB L2 cache and 667-MHz FSB (for use only with computers
equipped with UMA graphics memory subsystems)
501894-001
Before removing the processor, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 54).
5. Remove the following components:
a. Hard drive (see
Hard drive on page 63).
b. Optical drive (see
Optical drive on page 57).
c. Switch cover and keyboard (see
Switch cover and keyboard on page 70).
d. Display assembly (see
Display assembly on page 75).
e. Top cover (see
Top cover on page 85).
f. USB board (see
USB board on page 92).
Component replacement procedures 101

HP Pavilion dv6 Specifications

General

LED backlight	Yes
Display surface	Gloss
Display diagonal	15.6 \
Display brightness	200 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Bus type	DMI
Stepping	D2
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-2670QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	BGA 1224
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	2.2 GHz
Processor cache type	L3
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	22
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® HM65 Express
Memory slots	2x SO-DIMM
Internal memory	8 GB
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	2 x 4 GB
HDD size	2.5 \
HDD speed	5400 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
On-board graphics card ID	0x116
Discrete graphics card model	AMD Radeon HD 7690M XT
On-board graphics card model	Intel® HD Graphics 3000
Discrete graphics card memory	2 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1200 MHz
Audio system	Beats Audio
Number of built-in speakers	2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
HDMI ports quantity	-
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Home Premium
Form factor	Clamshell
Product type	Laptop
Product color	Silver
Country of origin	China
Processor code	SR02S
Processor ARK ID	53470
Processor package size	31 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Battery life (max)	- h
Number of battery cells	6
AC adapter power	120 W
Operating altitude	-15 - 3048 m
Non-operating altitude	-15 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	246.8 mm
Width	378 mm
Height	35.2 mm
Weight	2910 g
