Spare part

number

Description

511885-DJ1 Keyboard for use in Greece, Onyx

511887-001 Base enclosure (includes rubber feet)

511888-001 Top cover for use only with computer models not equipped with a fingerprint reader, Onyx (includes

TouchPad and TouchPad buttons, and speaker assembly)

511890-001 Plastics Kit (see Plastics Kit on page 34)

511892-001 Audio/infrared board (for use with computer models equipped with UMA graphics subsystem memory)

512357-001 16.0-inch WXGA BrightView display assembly with webcam and 2 microphones, Moonlight White

512358-001 16.0-inch WXGA AntiGlare display assembly with webcam and 2 microphones, Moonlight White

512359-001 Display bezel for use with computer models equipped with 16-inch BrightView displays (includes logo and

display lid switch actuator magnet)

512360-001 Display Hinge Kit for use only with computer models equipped with 16-inch BrightView display panels

(includes left and right hinges)

512361-001 Display Rubber Kit for BrightView displays (includes display bezel rubber screw covers)

512362-001 Display Screw Kit

512363-001 BrightView display panel for use only with computer models equipped with 15.6-inch display panels

(includes display panel cable)

512364-001 Display bezel for use with computer models equipped with 15.6-inch BrightView displays (includes logo

and display lid switch actuator magnet)

512365-001 Display Hinge Kit for use only with computer models equipped with 15.6-inch BrightView display panels

(includes left and right hinges)

512824-001 Display enclosure for 16-inch BrightView displays (includes wireless antenna transceivers and cables),

Onyx

512825-001 Display Cable for use with computers models equipped with BrightView display panels

512827-001 Webcam/microphone module (includes cable)

512828-001 Top cover for use only with computer models equipped with a fingerprint reader, Onyx (includes TouchPad

and TouchPad buttons, and speaker assembly)

512829-001 Switch cover (includes LED board and cable)

512830-001 Fan/heat sink assembly for use only with computer models equipped with graphics subsystems with UMA

graphics memory (includes replacement thermal material)

512832-001 Cable Kit (see Cable Kit on page 35)

512834-001 Power button board for computer models equipped with UMA graphics subsystem memory (includes

cable)

512835-001 Power button board for computers with discrete graphics subsystem memory (includes cable)

512836-001 Audio infrared board for use with computer models equipped with graphics subsystems with discrete

graphics memory

512837-001 Fan/heat sink assembly for use only with computer models equipped with graphics subsystems with

discrete graphics memory (includes replacement thermal material)

513477-001 Display Hinge Kit for 16-inch AntiGlare displays (includes left and right hinges)

513478-001 Display enclosure for 16-inch AntiGlare displays (includes wireless antenna transceivers and cables),

Onyx

42 Chapter 3 Illustrated parts catalog
