Illustrated Parts Catalog
Maintenance and Service Guide 3–3
Table 3-1
Spare Parts: Computer Major Components
Item Description
Spare Part
Number
1 Display assemblies (include wireless antenna transceivers
and cables)
For use with full-featured computer models with camera (includes
camera, camera cable, and microphones)
15.4-inch, WXGA, TFT with BrightView for use only
with computer models sold at Best Buy
15.4-inch, WXGA, TFT Antiglare for use only with
computer models sold at Best Buy
436258-001
436259-001
15.4-inch, WXGA, TFT with BrightView
15.4-inch, WXGA, TFT Antiglare
432298-001
431380-001
For use with full-featured computer models without camera
(includes microphones)
15.4-inch, WXGA, TFT with BrightView
15.4-inch, WXGA, TFT Antiglare
432299-001
432301-001
For use with defeatured computer models (does not include camera,
camera cable, or microphones)
15.4-inch, WXGA, TFT with BrightView
15.4-inch, WXGA, TFT Antiglare
432296-001
432297-001
✎
Refer to Section 3.3, “Display Assembly Components,” for
display assembly internal component spare part number
information.
2 Switch covers (include LED board and LED board cable)
For use with full-featured computer models
For use with defeatured computer models
431423-001
431422-001
3 Power button board (includes power button
board cable)
431437-001
