Bottom components
Item Description Function
1 Battery bay Holds the battery.
2 Battery Release latch Releases the battery from the battery bay.
3 Vents (7) Enable airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool internal
components and prevent overheating. It is normal for the internal
fan to cycle on and off during routine operation.
4 Primary Hard Drive bay Holds the primary hard drive, the memory module, and the WLAN
module (select models only).
CAUTION: To prevent an unresponsive system, replace the
wireless module with a wireless module authorized for use by the
governmental agency that regulates wireless devices in your
country or region. If you replace the module and then receive a
warning message, remove the module to restore computer
functionality, and then contact technical support through Help and
Support.
5 Integrated subwoofer Provides superior bass sound.
ENWW
Bottom components
13
