Spare part
number
Description
603784-001 500-GB, 7200-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with tab,
and 4 rubber isolators)
603785-001 640-GB, 5400-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with tab,
and 4 rubber isolators)
603787-001 750-GB, 5400-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with tab,
and 4 rubber isolators)
603788-001 1-TB, 5400-rpm hard drive (includes left and right bracket rails, connector cable, Mylar cover with tab,
and 4 rubber isolators)
604787-001 Fan/heat sink assembly for use only with computer models equipped with discrete memory
605319-001 System board with ATI Mobility Radeon HD 5470 discrete graphics subsystem and 512-MB of dedicated
memory (Dual Core), but no subwoofer
605320-001 System board with ATI Mobility Radeon HD 5650 discrete graphics subsystem and 1-GB of dedicated
memory (Quad core), but no subwoofer
605321-001 System board with ATI Mobility Radeon HD 5650 discrete graphics subsystem and 1-GB of dedicated
memory (Dual core), but no subwoofer
605322-001 System board with Intel HM55 HD UMA graphics subsystem and shared memory, but no subwoofer
605323-001 Bluetooth module cable
605324-001 17.3-inch HD+ standard display assembly with webcam and 2 microphones for use in silver computers
(includes wireless antenna transceivers and cables)
605325-001 17.3-inch HD+ flush glass AntiGlare display assembly with webcam and 2 microphones for use in silver
computers
605327-001 17.3-inch HD+ standard display assembly with webcam and 2 microphones for use in black computers
605330-001 Display enclosure for use with flush glass displays in silver computers (includes wireless antenna
transceivers and cables and logo LED board and cable)
605331-001 Display enclosure for use with standard displays in black computers (includes wireless antenna
transceivers and cables and logo LED board and cable)
605332-001 Display Screw Kit
605333-001 Display Cable Kit (includes display panel cable, and Webcam cable)
605334-001 Display Hinge Kit (includes right and left hinges) for use with flush glass displays
605336-001 Display hinge cover for use with flush glass displays
605337-001 BrightView display panel (includes display panel cable)
605338-001 Display enclosure for use in silver computer models with standard displays (includes wireless antenna
transceivers and cables and logo LED board and cable)
605339-001 Display enclosure for use in white computer models with standard displays (includes wireless antenna
transceivers and cables and logo LED board and cable)
605340-001 Display bezel for use with standard displays
605341-001 Display Rubber Kit (not illustrated, includes display bezel rubber screw covers)
34 Chapter 3 Illustrated parts catalog ENWW
