HP Pavilion dv9500 - Entertainment Notebook PC Maintenance And Service Guide

i. Audio board (see Audio board on page 97)
j. Front USB board (see
Front USB board on page 84)
k. Top cover trim (see
Top cover trim on page 87)
l. System board (see
System board on page 92)
Remove the fan/heat assembly:
1. Turn the system board upside down, with the expansion port 3 and external monitor port toward
you.
2. Disconnect the fan cable (1) from the system board.
3. Loosen the three Phillips PM2.5×5.0 captive screws (2) that secure the fan/heat sink assembly to
the system board.
100 Chapter 4 Removal and replacement procedures

HP Pavilion dv9500 - Entertainment Notebook PC Specifications

General

Processor	Intel Core 2 Duo
Memory	Up to 4 GB DDR2
Graphics	NVIDIA GeForce 8600M GS
Operating System	Windows Vista Home Premium
Audio	Altec Lansing speakers
HDMI Port	Yes
Chipset	Intel PM965 Express
Display Size	17.0 inch
Display Resolution	1440 x 900 (WXGA+)
Hard Drive	Up to 320 GB
Optical Drive	DVD±RW with Double Layer Support
Wireless	802.11a/b/g
Battery	6-cell Lithium-Ion
Weight	3.5 kg
USB Ports	3 x USB 2.0
