Front
Component Description
Speakers (2) Produce sound
Right side
Component Description
(1) Optical drive Plays optical discs, such as CDs, DVDs, and Blu-ray discs
(2) Optical drive light Green: The optical drive is being accessed.
(3) USB port Connects an optional USB device
(4) AC adapter light
●
Blinking white: The battery is low.
●
Solid white: The computer is connected to external
power.
●
Amber: The computer is charging the battery.
●
Off: The computer is not connected to external power.
(5) Power connector Connects an AC adapter
(6) Security cable slot Attaches an optional security cable to the computer
NOTE: The security cable is designed to act as a deterrent,
but it may not prevent the computer from being mishandled
or stolen.
8 Chapter 2 Getting to know your computer
